| اسم العلامة التجارية: | Womeng |
| رقم الطراز: | WM-SLP01 |
| الـ MOQ: | 1 |
| السعر: | $800,000.00-$9500,000.00 |
| تفاصيل التعبئة: | صندوق خشبي صالح |
| شروط الدفع: | L/C ، D/A ، D/P ، T/T ، Western Union ، Moneygram |
| Product size | 40m*6m*4m (for reference only) |
| Product structure | Upper & lower tissue, cotton core (mix with SAP), cover sheet hydrophilic non-woven, ADL (Acquisition distribution layer) non-woven, leak guard hydrophobic non-woven back sheet, Waist band non-woven, color pattern sticker, elastic waist band, discarding sticker. |
| Control system | PLC control system, HMI Operating on the LED touch screen, Configure HDTV monitor |
| Drive system | Servo Drive (Easy to change size), timing belt and flat belt are import products, and all the key parts, are import bearings. |
| Tension system | Top tissue paper, bottom tissue paper, hydrophobic nonwoven (leg cuff), top nonwoven, ADL, back sheet, elastic nonwoven are adopt A&B shaft active unwinding by inverter motor. |
| Safety system | Safety device on the operating side, matched with urgent stop switch. High audio fan uses sound insulation or silencer. |
| Packaging system | According to customer requirements with palletizer machine (double push double exit) adjustable |
| Materials corrective system | Adopt international famous brand deviation correction system |
| Power | 380V, 50HZ three phase five wire |
| Machine Capacity | 400KW (Excluding glue machine and air compressor) |
| Bleed pressure | 0.6-0.8Mpa (Air compressor needs to be prepared by customers) |
| Machine weight | 100 Tons approximately |
فيديو
فيديو
فيديو
فيديو
فيديو
فيديو
فيديو
فيديو
|
| اسم العلامة التجارية: | Womeng |
| رقم الطراز: | WM-SLP01 |
| الـ MOQ: | 1 |
| السعر: | $800,000.00-$9500,000.00 |
| تفاصيل التعبئة: | صندوق خشبي صالح |
| شروط الدفع: | L/C ، D/A ، D/P ، T/T ، Western Union ، Moneygram |
| Product size | 40m*6m*4m (for reference only) |
| Product structure | Upper & lower tissue, cotton core (mix with SAP), cover sheet hydrophilic non-woven, ADL (Acquisition distribution layer) non-woven, leak guard hydrophobic non-woven back sheet, Waist band non-woven, color pattern sticker, elastic waist band, discarding sticker. |
| Control system | PLC control system, HMI Operating on the LED touch screen, Configure HDTV monitor |
| Drive system | Servo Drive (Easy to change size), timing belt and flat belt are import products, and all the key parts, are import bearings. |
| Tension system | Top tissue paper, bottom tissue paper, hydrophobic nonwoven (leg cuff), top nonwoven, ADL, back sheet, elastic nonwoven are adopt A&B shaft active unwinding by inverter motor. |
| Safety system | Safety device on the operating side, matched with urgent stop switch. High audio fan uses sound insulation or silencer. |
| Packaging system | According to customer requirements with palletizer machine (double push double exit) adjustable |
| Materials corrective system | Adopt international famous brand deviation correction system |
| Power | 380V, 50HZ three phase five wire |
| Machine Capacity | 400KW (Excluding glue machine and air compressor) |
| Bleed pressure | 0.6-0.8Mpa (Air compressor needs to be prepared by customers) |
| Machine weight | 100 Tons approximately |
